T201MH9AQE

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Toggle Switches
Description Switch Toggle ON None ON DPDT Round Lever PC Pins 3A 120VAC 28VDC PC Mount with Bracket
PDF
/
Inventory: 7286
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Actuator Length 5.44mm
Length 8.13mm

Technical

Bushing Thread Unthreaded
Max Voltage Rating (DC) 28V
Illumination Non-Illuminated
Electrical Life 60,000 Cycles
Max Current Rating 3A
Max Voltage Rating (AC) 120V
Switch Function On-On
Circuit DPDT
Actuator Type Standard Round
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 3A
Orientation Right Angle
Current Rating (Amps) 3A AC/DC
Voltage - Rated DC 28V
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series T
Published 2016
Packaging Tray
Operating Temperature -30°C~85°C

Physical

Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle
Mount Brackets, Through Hole
Contact Material Silver

Supply Chain

Factory Lead Time 16 Weeks
