T101SCFZQE

C&K
RoHS
RoHS RoHS compliant
Package 120
Category Switches / Toggle Switches
Description SWITCH TOGGLE SPDT 3A 120V
PDF
/
Buying Options
Total Price: USD $7.29
Unit Price: USD $7.289321
≥1 USD $7.289321
≥10 USD $6.876712
≥100 USD $6.487468
≥500 USD $6.120255
≥1000 USD $5.773822
Inventory: 8001
Minimum: 1
-
+

Technical Details

Compliance

Ratings Dust Tight, IP67, Waterproof
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Actuator Length 7.11mm
Length 10.16mm

Technical

Bushing Thread 1/4-40
Contact Current Rating 3A
Max Voltage Rating (DC) 28V
Illumination Non-Illuminated
Electrical Life 60,000 Cycles
Max Current Rating 3A
Max Voltage Rating (AC) 120V
Contact Resistance 20mOhm
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On
Circuit SPDT
Actuator Type Standard Round
Voltage - Rated AC 120V
Termination Style Solder Lug
Current Rating 3A
Depth 10.16mm
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation Straight
Current Rating (Amps) 3A AC/DC
Voltage - Rated DC 28V
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series T
Published 2014
Packaging Bulk
Operating Temperature -30°C~85°C

Physical

Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Package / Case 120
Mounting Type Panel Mount
Mount Panel
Contact Material Silver

Supply Chain

Factory Lead Time 16 Weeks
