ET01MF1ABE
RoHS
/
Package /
Category Switches / Toggle Switches
Description
Switch Toggle ON None ON SPDT Round Lever PC Pins 20VAC 20VDC 0.4VA PC Mount with Bracket
PDF
/
Inventory: 7017
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP57, Waterproof
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Actuator Length 6.10mm
Length 8.13mm
Height 5.08mm
Technical
Bushing Thread Unthreaded
Max Voltage Rating (DC) 20V
Illumination Non-Illuminated
Electrical Life 60,000 Cycles
Max Voltage Rating (AC) 20V
Contact Resistance 10mOhm
Switch Function On-On
Circuit SPDT
Actuator Type Standard Round
Voltage - Rated AC 20V
Termination Style PC Pin
Ingress Protection IP57 - Dust Protected, Waterproof
Orientation Right Angle
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Color Beige
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature ESD Conductive Bushing
Series ET
Published 2014
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Through Hole, Right Angle
Mount Brackets, Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 9 Weeks
