E207SYZGE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPDT 7.5A 125V
PDF
/
Buying Options
Total Price: USD $12.43
Unit Price: USD $12.425111
≥1 USD $12.425111
≥10 USD $11.721802
≥100 USD $11.058308
≥500 USD $10.432361
≥1000 USD $9.841849
Inventory: 1340
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP57, Waterproof
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Actuator Length 10.16mm
Technical
Bushing Thread 1/4-40
Max Voltage Rating (DC) 28V
Illumination Non-Illuminated
Electrical Life 40,000 Cycles
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-Off-Mom
Circuit DPDT
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 7.5A
Ingress Protection IP57 - Dust Protected, Waterproof
Orientation Straight
Current Rating (Amps) 7.5A AC/DC
Voltage - Rated DC 28V
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series E
Published 2013
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount
Mount Panel
Contact Plating Gold
Contact Material Gold, Silver
Supply Chain
Factory Lead Time 16 Weeks
