E101MD9V3GE
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 7.5A 125V
PDF
/
Buying Options
Total Price: USD $10.84
Unit Price: USD $10.8416
≥1 USD $10.8416
≥10 USD $9.79616
≥100 USD $8.85324
≥500 USD $8.53886
≥1000 USD $8.01504
≥3000 USD $7.334026
Inventory: 158
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP57, Waterproof
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Actuator Length 6.86mm
Technical
Bushing Thread Unthreaded
Contact Current Rating 7.5A
Max Voltage Rating (DC) 28V
Illumination Non-Illuminated
Electrical Life 40,000 Cycles
Max Voltage Rating (AC) 250V
Contact Resistance 10mOhm
Switch Function On-On
Circuit SPDT
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 7.5A
Ingress Protection IP57 - Dust Protected, Waterproof
Orientation Straight
Current Rating (Amps) 7.5A AC/DC
Voltage - Rated DC 28V
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series E
Published 2008
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Package / Case 125
Mounting Type Through Hole
Mount Brackets, PCB, Through Hole
Contact Plating Gold
Contact Material Gold, Silver
Supply Chain
Factory Lead Time 16 Weeks
