7411SDAV2ME
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Standard Round 7000 Panel Mount Right Angle Vertical Bulk Toggle Switch 12.45mm 5A 250V -30C~85C
PDF
/
Inventory: 6107
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Lead, Silver, Tin
Mount Brackets, Panel, Vertical
Mounting Type Panel Mount, Right Angle, Vertical
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Jumper needed to achieve triple throw
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Standard Round
Circuit DP3T
Switch Function On-On-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 250V
Electrical Life 40,000 Cycles
Throw Configuration 4P, 4PDT, DP3T
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 12.45mm
Compliance
RoHS Status ROHS3 Compliant
