7408SD9CBE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Standard Round 7000 Through Hole Bulk Toggle Switch 12.45mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Buying Options
Total Price: USD $39.69
Unit Price: USD $39.688967
≥1 USD $39.688967
Inventory: 9321
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 12.45mm
Technical
Bushing Thread Unthreaded
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Non-Illuminated
Throw Configuration 4P, 4PDT
Electrical Life 40,000 Cycles
Max Voltage Rating (AC) 20V
Switch Function On-Mom
Circuit 4PDT
Actuator Type Standard Round
Voltage - Rated AC 20V
Termination Style PC Pin
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Mounting Type Through Hole
Mount PC Mount, Through Hole
Contact Plating Gold
Contact Material Gold
Supply Chain
Factory Lead Time 14 Weeks
