7403SDAV2BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Standard Round 7000 Panel Mount Right Angle Vertical Bulk Toggle Switch 12.45mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Inventory: 7563
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 12.45mm
Technical
Bushing Thread 1/4-40
Illumination Type Illuminated, Non-Illuminated
Illumination Non-Illuminated
Throw Configuration 4P, 4PDT
Electrical Life 40,000 Cycles
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-Off-On
Circuit 4PDT
Actuator Type Standard Round
Voltage - Rated AC 20V
Termination Style PC Pin
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount, Right Angle, Vertical
Mount Brackets, Panel, Vertical
Contact Plating Gold
Contact Material Gold
Supply Chain
Factory Lead Time 14 Weeks
