7403P3DAV2BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Flat Anti-Rotation 7000 Panel Mount Right Angle Vertical Bulk Toggle Switch 13.21mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Inventory: 984
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Gold
Contact Plating Gold
Mount Brackets, Panel, Vertical
Mounting Type Panel Mount, Right Angle, Vertical
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Flat Anti-Rotation
Circuit 4PDT
Switch Function On-Off-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Electrical Life 40,000 Cycles
Throw Configuration 4P, 4PDT
Illumination Non-Illuminated
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 13.21mm
Compliance
RoHS Status ROHS3 Compliant
