7401P3Y9AV2BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Flat Anti-Rotation 7000 Through Hole Right Angle Vertical Bulk Toggle Switch 11.43mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Inventory: 3667
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Gold
Contact Plating Gold
Mount Brackets, Through Hole, Vertical
Mounting Type Through Hole, Right Angle, Vertical
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Depth 42.67mm
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Flat Anti-Rotation
Circuit 4PDT
Switch Function On-On
Max Voltage Rating (AC) 20V
Electrical Life 100,000 Cycles
Throw Configuration 4P, 4PDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread Unthreaded
Dimensions
Length 21.59mm
Actuator Length 11.43mm
Compliance
RoHS Status ROHS3 Compliant
