7305MD9AV2BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Standard Round 7000 Through Hole Right Angle Vertical Bulk Toggle Switch 6.86mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Inventory: 6650
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 6.86mm
Technical
Bushing Thread Unthreaded
Illumination Type Illuminated, Non-Illuminated
Illumination Non-Illuminated
Throw Configuration 3P, 3PDT
Electrical Life 40,000 Cycles
Switch Function Mom-Off-Mom
Circuit 3PDT
Actuator Type Standard Round
Voltage - Rated AC 20V
Termination Style PC Pin
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Through Hole, Right Angle, Vertical
Mount Brackets, Through Hole, Vertical
Contact Plating Gold
Contact Material Gold
Supply Chain
Factory Lead Time 14 Weeks
