7301TPABE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE 3PDT 0.4VA 20V
PDF
/
Inventory: 4501
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 17.45mm
Technical
Bushing Thread 15/32-32
Illumination Type Illuminated, Non-Illuminated
Illumination Non-Illuminated
Throw Configuration 3P, 3PDT
Electrical Life 100,000 Cycles
Panel Cutout Dimensions Circular - 11.91mm Dia
Switch Function On-On
Circuit 3PDT
Actuator Type Anti-Rotation
Voltage - Rated AC 20V
Termination Style PC Pin
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount, Right Angle
Mount Brackets, Panel
Contact Plating Gold
Contact Material Gold
Supply Chain
Factory Lead Time 14 Weeks
