7301P1HZBE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Flat Anti-Rotation 7000 Panel Mount Bulk Toggle Switch 21.33mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Buying Options
Total Price: USD $31.83
Unit Price: USD $31.829948
≥1 USD $31.829948
Inventory: 9030
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 21.33mm
Length 12.7mm
Technical
Bushing Thread 1/4-40
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Non-Illuminated
Throw Configuration 3P, 3PDT
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 20V
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On
Circuit 3PDT
Actuator Type Flat Anti-Rotation
Voltage - Rated AC 20V
Termination Style Solder Lug
Depth 16.51mm
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Mounting Type Panel Mount
Mount Panel
Contact Plating Gold
Contact Material Gold
Supply Chain
Factory Lead Time 14 Weeks
