7215TCWAQE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle Mom ON Mom SP3T Round Lever PC Pins 5A 250VAC 28VDC PC Mount with Bracket and Threads
PDF
/
Inventory: 4984
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 17.45mm
Length 12.7mm
Technical
Bushing Thread 15/32-32
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Non-Illuminated
Throw Configuration DP, DPDT, SP3T
Electrical Life 40,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Circular - 11.91mm Dia
Switch Function Mom-On-Mom
Circuit SP3T
Actuator Type Standard Round
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 5A
Depth 46.49mm
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation Right Angle
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Jumper needed to achieve triple throw
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Mounting Type Panel Mount, Right Angle
Mount Brackets, Panel
Contact Plating Silver
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
