7215SPY3ZGE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SP3T 5A 120V
PDF
/
Inventory: 6427
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Gold
Mount Panel
Mounting Type Panel Mount
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Jumper needed to achieve triple throw
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Current Rating 5A
Termination Style Solder Lug
Voltage - Rated AC 120V
Actuator Type Anti-Rotation
Circuit SP3T
Switch Function Mom-On-Mom
Panel Cutout Dimensions Circular - 6.50mm Dia
Electrical Life 40,000 Cycles
Throw Configuration DP, DPDT, SP3T
Illumination Non-Illuminated
Illumination Type Illuminated, Non-Illuminated
Bushing Thread M6 x 0.75
Dimensions
Actuator Length 10.67mm
Compliance
RoHS Status ROHS3 Compliant
