7213SPY9ABE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SP3T 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $25
Unit Price: USD $25.002868
≥1 USD $25.002868
Inventory: 4751
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 10.67mm
Length 12.7mm
Technical
Bushing Thread Unthreaded
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Non-Illuminated
Throw Configuration DP, DPDT, SP3T
Electrical Life 40,000 Cycles
Max Voltage Rating (AC) 20V
Switch Function On-On-Mom
Circuit SP3T
Actuator Type Anti-Rotation
Voltage - Rated AC 20V
Termination Style PC Pin
Depth 36.71mm
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Jumper needed to achieve triple throw
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle
Mount Brackets, Through Hole
Contact Plating Gold
Contact Material Gold
Supply Chain
Factory Lead Time 14 Weeks
