7207L2YZBE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle ON OFF Mom DPDT Round Lever Solder Lug 20VAC 20VDC 0.4VA Panel Mount with Threads
PDF
/
Inventory: 8837
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Gold
Contact Plating Gold
Mount Panel
Mounting Type Panel Mount
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Straight
Depth 11.43mm
Termination Style Solder Lug
Voltage - Rated AC 20V
Actuator Type Standard Round
Circuit DPDT
Switch Function On-Off-Mom
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 20V
Electrical Life 40,000 Cycles
Throw Configuration DP, DPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Length 12.7mm
Actuator Length 13.97mm
Compliance
RoHS Status ROHS3 Compliant
