7205P3D9V3BE22
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPDT 0.4VA 20V
PDF
/
Inventory: 5601
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 13.21mm
Technical
Bushing Thread Unthreaded
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Non-Illuminated
Throw Configuration DP, DPDT
Electrical Life 40,000 Cycles
Max Voltage Rating (AC) 20V
Switch Function Mom-Off-Mom
Circuit DPDT
Actuator Type Flat Anti-Rotation
Voltage - Rated AC 20V
Termination Style PC Pin
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Black Actuator
Series 7000
Published 2014
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass
Housing Material Stainless Steel
Mounting Type Through Hole
Mount Brackets, Through Hole
Contact Plating Gold
Contact Material Gold
Supply Chain
Factory Lead Time 14 Weeks
