7203P3D9AV2QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPDT 5A 120V
PDF
/
Inventory: 8492
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 13.21mm
Length 11.43mm
Technical
Bushing Thread Unthreaded
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Non-Illuminated
Throw Configuration DP, DPDT
Electrical Life 40,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Switch Function On-Off-On
Circuit DPDT
Actuator Type Flat Anti-Rotation
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 5A
Depth 41.02mm
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle, Vertical
Mount Brackets, Through Hole, Vertical
Contact Plating Gold, Silver
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
