7203P1DZ3BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPDT 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $23.28
Unit Price: USD $23.276404
≥1 USD $23.276404
Inventory: 7435
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Gold
Contact Plating Gold
Mount Panel
Mounting Type Panel Mount
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Termination Style Quick Connect - 0.062 (1.5mm)
Voltage - Rated AC 20V
Actuator Type Flat Anti-Rotation
Circuit DPDT
Switch Function On-Off-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Electrical Life 40,000 Cycles
Throw Configuration DP, DPDT
Illumination Non-Illuminated
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 23.11mm
Compliance
RoHS Status ROHS3 Compliant
