7203L2PY1AV2BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Anti-Rotation 7000 Panel Mount Right Angle Vertical Bulk Toggle Switch 13.97mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Inventory: 7140
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Gold
Contact Plating Gold
Mount Brackets, Panel, Vertical
Mounting Type Panel Mount, Right Angle, Vertical
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Anti-Rotation
Circuit DPDT
Switch Function On-Off-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 20V
Electrical Life 40,000 Cycles
Throw Configuration DP, DPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 13.97mm
Compliance
RoHS Status ROHS3 Compliant
