7201P3YCBE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Flat Anti-Rotation 7000 Panel Mount Bulk Toggle Switch 11.43mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Buying Options
Total Price: USD $12.51
Unit Price: USD $12.514144
≥1 USD $12.514144
≥10 USD $11.805795
≥100 USD $11.137549
≥500 USD $10.507115
≥1000 USD $9.912373
Inventory: 3275
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Gold
Mount Panel
Mounting Type Panel Mount
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Straight
Depth 11.43mm
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Flat Anti-Rotation
Circuit DPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 20V
Electrical Life 100,000 Cycles
Throw Configuration DP, DPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Length 12.7mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
