7201P3DAV2QE
RoHS
RoHS compliant
RoHS compliantPackage Epoxy
Category Switches / Toggle Switches
Description
Switch Toggle ON None ON DPDT Flat Lever PC Pins 5A 250VAC 28VDC PC Mount with Bracket and Threads
PDF
/
Buying Options
Total Price: USD $16.47
Unit Price: USD $16.4736
≥1 USD $16.4736
≥10 USD $14.96
≥100 USD $14.28768
≥500 USD $13.53132
≥1000 USD $13.026974
≥3000 USD $12.186495
Inventory: 157
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Mount Brackets, Panel, Vertical
Mounting Type Panel Mount, Right Angle, Vertical
Package / Case Epoxy
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Tray
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Depth 41.02mm
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Flat Anti-Rotation
Circuit DPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 100,000 Cycles
Throw Configuration DP, DPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Length 11.43mm
Actuator Length 13.21mm
Compliance
RoHS Status ROHS3 Compliant
