7201P3CWWQE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle ON None ON DPDT Flat Lever Wire Wrap 5A 250VAC 28VDC Panel Mount with Threads
PDF
/
Inventory: 7483
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Gold, Silver
Mount Panel
Mounting Type Panel Mount
Housing Material Stainless Steel
Actuator Material Brass
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2014
Series 7000
Feature Black Actuator
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Orientation Straight
Ingress Protection IP67 - Dust Tight, Waterproof
Depth 11.81mm
Current Rating 5A
Termination Style Wire Wrap
Voltage - Rated AC 120V
Actuator Type Flat Anti-Rotation
Circuit DPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 100,000 Cycles
Throw Configuration DP, DPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Length 12.7mm
Actuator Length 11.43mm
Compliance
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP67, Waterproof
