7201MD9ARE

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Toggle Switches
Description Standard Round 7000 Through Hole Right Angle Bulk Toggle Switch 6.86mm 5A 250V -30C~85C
PDF
/
Buying Options
Total Price: USD $24.55
Unit Price: USD $24.547291
≥1 USD $24.547291
Inventory: 3064
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Actuator Length 6.86mm

Technical

Bushing Thread Unthreaded
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Non-Illuminated
Throw Configuration DP, DPDT
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 250V
Switch Function On-On
Circuit DPDT
Actuator Type Standard Round
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 5A
Orientation Right Angle
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2014
Packaging Bulk
Operating Temperature -30°C~85°C

Physical

Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle
Mount Brackets, Through Hole
Contact Plating Gold, Silver
Contact Material Silver

Supply Chain

Factory Lead Time 14 Weeks
