7201L41YW5BE2

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Toggle Switches
Description SWITCH TOGGLE DPDT 0.4VA 20V
PDF
/
Inventory: 6781
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Actuator Length 13.49mm
Length 12.7mm

Technical

Bushing Thread 1/4-40
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Non-Illuminated
Throw Configuration DP, DPDT
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 20V
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On
Circuit DPDT
Actuator Type Flat Anti-Rotation
Voltage - Rated AC 20V
Termination Style Wire Wrap
Depth 11.43mm
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Black Actuator
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C

Physical

Actuator Material Thermoplastic
Housing Material Stainless Steel
Mounting Type Panel Mount
Mount Panel
Contact Plating Gold
Contact Material Gold

Supply Chain

Factory Lead Time 14 Weeks
