7201K9ABE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Locking Lever 7000 Through Hole Right Angle Bulk Toggle Switch 17.88mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Buying Options
Total Price: USD $25.15
Unit Price: USD $25.151225
≥1 USD $25.151225
Inventory: 5067
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Gold
Contact Plating Gold
Mount Brackets, Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Stainless Steel
Actuator Material Aluminum
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Right Angle
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Locking Lever
Circuit DPDT
Switch Function On-On
Max Voltage Rating (AC) 20V
Electrical Life 100,000 Cycles
Throw Configuration DP, DPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread Unthreaded
Dimensions
Actuator Length 17.88mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
