7201K12CBE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Locking Lever 7000 Panel Mount Bulk Toggle Switch 18.59mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Buying Options
Total Price: USD $20.76
Unit Price: USD $20.76225
≥1 USD $20.76225
≥10 USD $17.0354
≥100 USD $16.5034
≥500 USD $15.97045
≥1000 USD $15.43845
Inventory: 34
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Gold
Mount Panel
Mounting Type Panel Mount
Housing Material Stainless Steel
Actuator Material Aluminum
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Straight
Depth 11.43mm
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Locking Lever
Circuit DPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 20V
Electrical Life 100,000 Cycles
Throw Configuration DP, DPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Length 12.7mm
Actuator Length 18.59mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
