7108K2ZBE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle ON None Mom SPDT Locking Lever Solder Lug 20VAC 20VDC 0.4VA Panel Mount with Threads
PDF
/
Inventory: 8203
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Depth 6.86mm
Termination Style Solder Lug
Voltage - Rated AC 20V
Actuator Type Locking Lever
Circuit SPDT
Switch Function On-Mom
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 20V
Electrical Life 40,000 Cycles
Throw Configuration SP, SPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Dimensions
Length 12.7mm
Actuator Length 17.88mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Actuator Material Aluminum
Housing Material Stainless Steel
Mounting Type Panel Mount
Mount Panel
Contact Plating Gold
Contact Material Gold
Supply Chain
Factory Lead Time 14 Weeks
