7105P1YZQE
RoHS
/
Package /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 5A 120V
PDF
/
Inventory: 7704
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Gold, Silver
Mount Panel
Mounting Type Panel Mount
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Current Rating 5A
Termination Style Solder Lug
Voltage - Rated AC 120V
Actuator Type Flat Anti-Rotation
Circuit SPDT
Switch Function Mom-Off-Mom
Panel Cutout Dimensions Circular - 6.35mm Dia
Electrical Life 40,000 Cycles
Throw Configuration SP, SPDT
Illumination Non-Illuminated
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 21.33mm
Compliance
RoHS Status Non-RoHS Compliant
