7103SH4ZBE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 0.4VA 20V
PDF
/
Inventory: 7934
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Gold
Contact Plating Gold
Mount Panel
Mounting Type Panel Mount
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Termination Style Solder Lug
Voltage - Rated AC 20V
Actuator Type Standard Round
Circuit SPDT
Switch Function On-Off-On
Panel Cutout Dimensions Circular - 6.50mm Dia
Electrical Life 40,000 Cycles
Throw Configuration SP, SPDT
Illumination Non-Illuminated
Illumination Type Illuminated, Non-Illuminated
Bushing Thread M6 x 0.75
Dimensions
Actuator Length 10.67mm
Compliance
RoHS Status ROHS3 Compliant
