7103P4YWQE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Flat Anti-Rotation 7000 Panel Mount Bulk Toggle Switch 6.35mm 5A 250V -30C~85C
PDF
/
Inventory: 8919
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 6.35mm
Technical
Bushing Thread 1/4-40
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Non-Illuminated
Throw Configuration SP, SPDT
Electrical Life 40,000 Cycles
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-Off-On
Circuit SPDT
Actuator Type Flat Anti-Rotation
Voltage - Rated AC 120V
Termination Style Wire Wrap
Current Rating 5A
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount
Mount Panel
Contact Plating Gold
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
