7101SY9V7ME
RoHS
/
Package /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 5A 120V
PDF
/
Inventory: 7853
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Silver, Tin
Mount Brackets, Through Hole
Mounting Type Through Hole
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2003
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Orientation Straight
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Standard Round
Circuit SPDT
Switch Function On-On
Max Voltage Rating (AC) 250V
Electrical Life 100,000 Cycles
Throw Configuration SP, SPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread Unthreaded
Dimensions
Actuator Length 10.67mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
