7101MD9AME
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 5A 120V
PDF
/
Inventory: 7868
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 6.86mm
Length 12.7mm
Technical
Bushing Thread Unthreaded
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Non-Illuminated
Throw Configuration SP, SPDT
Electrical Life 100,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Switch Function On-On
Circuit SPDT
Actuator Type Standard Round
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 5A
Depth 27.31mm
Orientation Right Angle
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2003
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle
Mount Brackets, Through Hole
Contact Plating Lead, Silver, Tin
Contact Material Silver
Supply Chain
Factory Lead Time 11 Weeks
