7101K9V21GE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Locking Lever 7000 Through Hole Bulk Toggle Switch 17.88mm 5A 250V -30C~85C
PDF
/
Buying Options
Total Price: USD $21.73
Unit Price: USD $21.733747
≥1 USD $21.733747
Inventory: 1710
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Gold, Silver
Mount Brackets, Through Hole
Mounting Type Through Hole
Housing Material Stainless Steel
Actuator Material Aluminum
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Orientation Straight
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Locking Lever
Circuit SPDT
Switch Function On-On
Max Voltage Rating (AC) 250V
Electrical Life 100,000 Cycles
Throw Configuration SP, SPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread Unthreaded
Dimensions
Actuator Length 17.88mm
Compliance
RoHS Status ROHS3 Compliant
