C1750H
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPST 16A 250V
PDF
/
Buying Options
Total Price: USD $15.79
Unit Price: USD $15.7872
≥1 USD $15.7872
≥10 USD $14.15392
≥100 USD $13.531936
≥500 USD $12.831984
≥1000 USD $12.365408
≥3000 USD $11.587734
Inventory: 850
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mounting Type Panel Mount
Surface Mount NO
Actuator Material Polyamide (PA), Nylon
Center Contact Material SILVER ALLOY
End Contact Material SILVER ALLOY
Technical
Packaging Bulk
Published 2011
Series 1750
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 16A AC
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 250V
Actuator Type Flatted
Circuit DPST
Switch Function On-Off
Panel Cutout Dimensions Circular - 12.70mm Dia
Contact Resistance 0.1mOhm
Insulation Resistance 20000000Ohm
Dielectric Withstanding Voltage 3000VAC V
Electrical Life 10000 Cycle(s)
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Bushing Thread 15/32-32
Contact Current(AC)-Max 16A
Contact Voltage(AC)-Max 250V
Bushing Length 0.394 inch
Dimensions
Body Height 19.2024mm
Length - Termination 0.358 inch
Actuator Length 16.40mm
Compliance
RoHS Status ROHS3 Compliant
