ST26KMCB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Standard Round ST Panel Mount Bulk Toggle Switch 10.41mm 0.02A 20V 0.003mOhm
PDF
/
Inventory: 8160
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Actuator Length 10.41mm
Length - Termination 0.25 inch
Body Height 10.57mm
Technical
Actuator Finish BRIGHT NICKEL/CHROME
Body Color RED
Bushing Length 0.275 inch
PCB Hole Count 6
Contact Voltage(AC)-Max 20V
Contact Current(AC)-Max 0.02A
Bushing Thread 1/4-40
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 40,000 Cycles
Dielectric Withstanding Voltage 2000VAC V
Contact Voltage(DC)-Max 20V
Contact Current(DC)-Max 0.02A
Insulation Resistance 200000000000Ohm
Contact Resistance 0.003mOhm
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On-On
Circuit SP3T
Actuator Type Standard Round
Body Breadth 12.73 mm
Body Length or Diameter 13.06mm
Voltage - Rated AC 20V
Termination Style PC Pin
Reach Compliance Code compliant
Current Rating (Amps) 0.4VA AC/DC
HTS Code 8536.50.90.65
Terminal Finish Gold (Au)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Jumper needed to achieve triple throw
JESD-609 Code e4
Series ST
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
End Contact Plating GOLD OVER NICKEL
Center Contact Plating GOLD OVER NICKEL
Actuator Material Brass, Nickel Plated
Insulation Material DIALLYL PHTHALATE
Surface Mount NO
Mounting Type Panel Mount
