647NH/2
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPDT 10A 125V
PDF
/
Buying Options
Total Price: USD $31.1
Unit Price: USD $31.099975
≥1 USD $31.099975
≥200 USD $12.409531
≥500 USD $11.994654
≥1000 USD $11.789842
Inventory: 1206
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Actuator Length 13.50mm
Body Height 21.5mm
Technical
Contact (DC) Max Rating R Load 5A@25VDC
Bushing Thread M12 x 0.75
Illumination Type Illuminated, Non-Illuminated
Contact Current Rating 15A
Switch Type TOGGLE SWITCH
Max Voltage Rating (DC) 25V
Illumination Non-Illuminated
Electrical Life 10,000 Cycles
Contact Current(DC)-Max 5A
Contact Resistance 10mOhm
Panel Cutout Dimensions Circular - 12.20mm Dia
Switch Function Mom-Off-Mom
Circuit DPDT
Actuator Type Flatted
Body Breadth 21.5 mm
Body Length or Diameter 29.7mm
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 10A
Orientation Straight
Current Rating (Amps) 10A AC
HTS Code 8536.50.90.40
Additional Feature O.F. = 1.5 NM
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 600NH
Packaging Bulk
Operating Temperature -20°C~55°C
Physical
Actuator Material Polyamide (PA), Nylon
Package / Case 125
Mounting Type Panel Mount
Mount Panel
Contact Material Silver
Supply Chain
Factory Lead Time 9 Weeks
