5648AB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Toggle switch Standard Lever on-off-(on) 2 P, 5648AB, Apem
PDF
/
Buying Options
Total Price: USD $10.73
Unit Price: USD $10.7272
≥1 USD $10.7272
≥10 USD $9.68968
≥100 USD $9.223456
≥500 USD $8.757056
≥1000 USD $8.446152
≥3000 USD $7.92799
Inventory: 92
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Silver
Mount Panel
Mounting Type Panel Mount
Actuator Material Brass, Nickel Plated
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series 5000
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
HTS Code 8536.50.90.65
Voltage - Rated DC 30V
Current Rating (Amps) 6A AC 4A DC
Current Rating 4A
Termination Style Solder Lug
Voltage - Rated AC 125V
Body Length or Diameter 13.2mm
Body Breadth 12 mm
Actuator Type Standard Round
Circuit DPDT
Switch Function On-Off-Mom
Panel Cutout Dimensions Circular - 6.50mm Dia
Contact Current(DC)-Max 4A
Sealing EPOXY TERMINAL SEALED
Electrical Life 50,000 Cycles
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Bushing Thread 1/4-40
Contact Current(AC)-Max 6A
Contact (AC) Max Rating R Load 6A@125VAC
Dimensions
Body Height 12mm
Actuator Length 10.50mm
Compliance
RoHS Status ROHS3 Compliant
