5638MADGBK
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 6A 125V
PDF
/
Buying Options
Total Price: USD $150.49
Unit Price: USD $150.487224
≥1 USD $150.487224
≥200 USD $60.045482
≥500 USD $58.03937
≥1000 USD $57.048131
Inventory: 2162
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 17.50mm
Technical
Bushing Thread 15/32-32
Illumination Type Non-Illuminated
Illumination Non-Illuminated
Throw Configuration SPDT
Electrical Life 50,000 Cycles
Panel Cutout Dimensions Circular - 12.50mm Dia
Switch Function On-Off-Mom
Circuit SPDT
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 4A
Current Rating (Amps) 6A AC 4A DC
Voltage - Rated DC 30V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Matte Black Finish
Series 5000M
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Brass, Nickel Plated
Mounting Type Panel Mount
Mount Panel
Supply Chain
Factory Lead Time 14 Weeks
