5638AB9
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Flatted 5000 Panel Mount Bulk Toggle Switch 11.40mm 4A 125V 6A@125VAC
PDF
/
Buying Options
Total Price: USD $7.23
Unit Price: USD $7.2336
≥1 USD $7.2336
≥10 USD $6.53136
≥100 USD $6.217024
≥500 USD $6.149088
Inventory: 139
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Panel
Mounting Type Panel Mount
Actuator Material Polyamide (PA), Nylon
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series 5000
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Terminal Finish Silver (Ag)
HTS Code 8536.50.90.65
Voltage - Rated DC 30V
Current Rating (Amps) 6A AC 4A DC
Current Rating 4A
Termination Style Solder Lug
Voltage - Rated AC 125V
Body Length or Diameter 13.2mm
Body Breadth 7 mm
Actuator Type Flatted
Circuit SPDT
Switch Function On-Off-Mom
Panel Cutout Dimensions Circular - 6.50mm Dia
Contact Current(DC)-Max 4A
Sealing EPOXY TERMINAL SEALED
Electrical Life 50,000 Cycles
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Contact Current Rating 4A
Bushing Thread 1/4-40
Contact Current(AC)-Max 6A
Contact (AC) Max Rating R Load 6A@125VAC
Dimensions
Body Height 12mm
Actuator Length 11.40mm
Compliance
RoHS Status ROHS3 Compliant
