5246WWCDB16X445
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Standard Round 5000 Through Hole Right Angle Vertical Bulk Toggle Switch 8.50mm 0.02A 20V .02A@20VAC
PDF
/
Inventory: 2897
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 8.50mm
Body Height 13.2mm
Technical
Contact (DC) Max Rating R Load .02A@20VDC
Contact (AC) Max Rating R Load .02A@20VAC
Contact Current(AC)-Max 0.02A
Bushing Thread Unthreaded
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 50,000 Cycles
Sealing EPOXY TERMINAL SEALED
Contact Current(DC)-Max 0.02A
Switch Function On-On
Circuit DPDT
Actuator Type Standard Round
Body Breadth 11 mm
Body Length or Diameter 12mm
Voltage - Rated AC 20V
Termination Style PC Pin
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
HTS Code 8536.50.90.65
Terminal Finish Gold (Au)
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
JESD-609 Code e4
Series 5000
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Brass, Nickel Plated
Mounting Type Through Hole, Right Angle, Vertical
Mount Through Hole, Vertical
Supply Chain
Factory Lead Time 9 Weeks
