12244AG3VX408
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SP3T 4A 125V
PDF
/
Buying Options
Total Price: USD $99.38
Unit Price: USD $99.3784
≥1 USD $99.3784
≥10 USD $89.43792
≥100 USD $85.930944
≥500 USD $80.08528
≥1000 USD $72.347
Inventory: 101
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 20.60mm
Body Height 13.7mm
Technical
Bushing Thread 15/32-32
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Throw Configuration DP3T
Electrical Life 50,000 Cycles
Sealing DUST PROOF; EPOXY TERMINAL SEALED; WATER PROOF
Contact Current(DC)-Max 4A
Panel Cutout Dimensions Circular - 12.00mm Dia
Switch Function On-On-On
Circuit SP3T
Actuator Type Locking Lever
Body Length or Diameter 18.2mm
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 4A
Current Rating (Amps) 4A AC/DC
Voltage - Rated DC 30V
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Jumper needed to achieve triple throw
Series 12000
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount
Mount Panel
Supply Chain
Factory Lead Time 9 Weeks
