DLD2425
RoHS
RoHS compliant
RoHS compliantPackage /
Category Industrial Automation and Controls / Time Delay Relays
Description
RELAY TIME DELAY 133SEC 25A 280V
PDF
/
Buying Options
Total Price: USD $183.14
Unit Price: USD $183.137034
≥1 USD $183.137034
≥10 USD $172.77078
≥100 USD $162.99131
≥500 USD $153.765387
≥1000 USD $145.061679
Inventory: 980
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 45.7mm
Length 58.4mm
Height 22.2mm
Technical
Timing Initiate Method Input Voltage
Timing Adjustment Method External Resistor
Delay Time 1.6 Sec ~ 133 Sec
Load Current 25A
Input Current 11.4mA
Contact Rating @ Voltage 25A @ 280VAC
Relay Type Solid State Relay
Throw Configuration SPST
Output Current 25A
Circuit SPST-NO (1 Form A)
Approval Agency UL
Voltage - Rated AC 280V
Function On-Delay
Termination Style Screw Terminal, Quick Connect - 0.187 (4.7mm)
Current Rating 25A
Voltage - Supply 3.5V~15VDC
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Not For New Designs
Series DLD
Published 2008
Physical
Number of Pins 6
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw
Supply Chain
Factory Lead Time 8 Weeks
