2917447
RoHS
RoHS compliant
RoHS compliantPackage 300
Category Industrial Automation and Controls / Time Delay Relays
Description
Time Delay & Timing Relays ETD-BL1T-ON-CC300MIN
PDF
/
Inventory: 1174
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP20
RoHS Status RoHS Compliant
Dimensions
Width 6.2mm
Length 80mm
Height 86mm
Technical
Switching Capacity 1.125 kW
Timing Initiate Method Input Voltage
Timing Adjustment Method Screwdriver Slot
Delay Time 3 Min ~ 300 Min
Coil Voltage (DC) 24V
Contact Rating @ Voltage 6A @ 250VAC
Relay Type Mechanical Relay
Throw Configuration SPDT
Max Current Rating 6.3A
Circuit SPDT (1 Form C)
Operating Supply Voltage 30V
Number of Contacts 1
Function On-Delay
Termination Style Screw Terminal
Current Rating 6.3A
Depth 86mm
Voltage - Supply 24VDC
Voltage - Rated DC 30V
Min Operating Temperature -20°C
Max Operating Temperature 65°C
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ETD-BL-1T
Published 2009
Physical
Weight 50.9g
Package / Case 300
Mounting Type DIN Rail
Mount DIN Rail
Supply Chain
Factory Lead Time 5 Weeks
