Package /
Category Industrial Automation and Controls / Time Delay Relays
Description On-Delay DPDT (2Form C) Plug In 8Pin (Octal) Mechanical Relay Delay Relay 12VDC 10A @ 120/240VAC 1Sec-1023Sec
PDF
/
Inventory: 8604
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mounting Type Socketable

Technical

Published 2016
Series TDM
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Voltage - Supply 12VDC
Termination Style Plug In, 8 Pin (Octal)
Function On-Delay
Circuit DPDT (2 Form C)
Relay Type Mechanical Relay
Contact Rating @ Voltage 10A @ 120/240VAC
Delay Time 1 Sec ~ 1023 Sec
Timing Adjustment Method DIP Switches
Timing Initiate Method Input Voltage

Compliance

RoHS Status ROHS3 Compliant
