88867435
RoHS
/
Package /
Category Industrial Automation and Controls / Time Delay Relays
Description
RELAY TIME DELAY 100HRS 10A 250V
PDF
/
Inventory: 9128
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Silver
Mount Plug-In, Socket
Mounting Type Socketable
Number of Pins 11
Technical
Published 2001
Series PC2R1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Plug
Max Operating Temperature 60°C
Min Operating Temperature -20°C
Voltage - Rated DC 24V
Voltage - Supply 24V~240VAC
Depth 78mm
Current Rating 10A
Termination Style Plug In, 11 Pin (Octal)
Function Off-Delay
Voltage - Rated AC 24V
Approval Agency CE, CSA, UL
Number of Contacts 2
Operating Supply Voltage 240V
Circuit DPDT (2 Form C)
Max Current Rating 8A
Nominal Supply Current 10A
Throw Configuration DPDT
Relay Type Mechanical Relay
Contact Rating @ Voltage 10A @ 250VAC
Coil Voltage (DC) 24V
Max Supply Voltage (AC) 240V
Coil Voltage (AC) 24V
Delay Time 0.1 Sec ~ 100 Hrs
Timing Adjustment Method Hand Dial
Timing Initiate Method Input Voltage, Trigger Signal
Dimensions
Length 45mm
Width 35mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
