88826135
RoHS
/
Package 100
Category Industrial Automation and Controls / Time Delay Relays
Description
CROUZET AUTOMATION 88 826 135 TIMER, IMPULSE
PDF
/
Inventory: 1436
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 17.5mm
Length 81mm
Height 81mm
Technical
Nominal Input Voltage (AC) 240V
Min Supply Voltage (AC) 24V
Timing Initiate Method Input Voltage, Trigger Signal
Timing Adjustment Method Screwdriver Slot
Delay Time 0.1 Sec ~ 100 Hrs
Coil Voltage (AC) 240V
Max Supply Voltage (AC) 240V
Coil Voltage (DC) 24V
Contact Rating @ Voltage 8A @ 250VAC
Power Consumption 1.5W
Relay Type Mechanical Relay
Contact Current Rating 8A
Accuracy 0.5 %
Throw Configuration SPDT
Output Current 8A
Nominal Supply Current 10A
Max Current Rating 10A
Max Voltage Rating (AC) 250V
Circuit SPDT (1 Form C)
Operating Supply Voltage 240V
Number of Contacts 1
Approval Agency CE, CSA, UL
Voltage - Rated AC 250V
Function Off-Delay
Termination Style Screw Terminal
Current Rating 8A
Depth 60mm
Voltage - Supply 24V~240VAC 24VDC
Min Operating Temperature -20°C
Max Operating Temperature 60°C
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series MCR1
Published 2003
Physical
Number of Pins 6
Package / Case 100
Mounting Type DIN Rail
Mount DIN Rail
Contact Material Silver
