BTA208-600D,127
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC SENS GATE 600V 8A TO220AB
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3256
≥1 USD $0.3256
Inventory: 329824
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Triac Type Logic - Sensitive Gate
Repetitive Peak Off-state Voltage 600V
Current - On State (It (RMS)) (Max) 8A
Current - Hold (Ih) (Max) 15mA
Current - Gate Trigger (Igt) (Max) 5mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 65A 72A
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Voltage - Off State 600V
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
JEDEC-95 Code TO-220AB
Case Connection MAIN TERMINAL 2
Configuration Single
Number of Elements 1
JESD-30 Code R-PSFM-T3
Reference Standard IEC-60134
Base Part Number BTA208
HTS Code 8541.30.00.80
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tube
Operating Temperature 125°C TJ
Physical
Surface Mount NO
Package / Case TO-220-3
Mounting Type Through Hole
