BT138X-600D,127
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack, Isolated Tab
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
Tube Through Hole Logic - Sensitive Gate Single TRIAC 95A 105A 10mA 600V 125C TJ
PDF
/
Inventory: 4119
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack, Isolated Tab
Surface Mount NO
Technical
Operating Temperature 125°C TJ
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin (Sn)
HTS Code 8541.30.00.80
Reach Compliance Code not_compliant
Base Part Number BT138
Reference Standard IEC-60134
JESD-30 Code R-PSFM-T3
Number of Elements 1
Configuration Single
JEDEC-95 Code TO-220AB
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Voltage - Off State 600V
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 95A 105A
Current - Gate Trigger (Igt) (Max) 10mA
Current - Hold (Ih) (Max) 30mA
Current - On State (It (RMS)) (Max) 12A
Repetitive Peak Off-state Voltage 600V
Triac Type Logic - Sensitive Gate
Compliance
RoHS Status RoHS Compliant
